Meshy type angle iron machine

Different with traditional wall angles, now the meshy type wall angle is quite popular. The meshy type wall angel either could be used with ceiling or drywall building to make the ceiling or drywall stronger. Base on this need, we developed new type meshy type wall angle roll forming machine. Here are some pictures of meshy type wall angle for your reference:

Meshy-type-angle-iron machine

Work process of Meshy Type Wall Angle Roll forming machine

decoiling(decoiler) coiler feeder(for sending coil to the punching machine)punching   punching(punching mesh size by punching) feeding roll forming machine shearing and cutting  runout table.

Meshy-type-angle-iron machine-1

The meshy type wall angle roll forming machine is composed by the following elements:

No.Item Name Quantity
1Decoiler

Option A: Hydraulic Decoiler

Option B: Motor Decoiler

Option C: Manual Decoiler

 1 SET
2Coiler feeder1 SET
3Leveling part1 SET
4Punching part1 SET
5Roll forming part1 SET
6Shearing and cutting part1 SET
7Hydraulic Station1 SET
8PLC control system1 SET
9Runout table1 SET



Machine meshy wall angle roll forming machine:

Meshy-type-angle-iron-machine-2

Main part introduction:
Punching part
This part will be punching coil to meshy type and for further roll forming.

Meshy-type-angle-iron-machine-3

Here is the main roll forming machine pictures for your reference:

Meshy-type-angle-iron-machine-4
