C/U Channel Roll Forming Machine
Introduction
C/U Channel Roll Forming Machine is famous for its strong and durable design and Zhongtuo light keel roll forming machines add more features based on these capacities. The machines stated here is able to process metal sheet up to 6mm.Light steel keel now is wildly used in industry factory civil construction such as plate, warehouse, exhibition building, stadium and son on. Except C shape, U shape, we can also make V shape, L shape keels. Meanwhile we could also provides customization, all you need sending us the keel drawings then we can make for you.
Component of C/U Channel Roll Forming Machine
This roll forming machine is made up of uncoiler(decoiler), feeding system, leveling device, roll forming unit, rear cutting part and run out table.
Work flow of machine.
Features of C/U Channel Roll Forming Machine
- We can design pouncing dies according to customer requirements.
- Keel shape mold could be customized.
- Round circle with protection arm for protecting coil from loosing.
- Leveling system make sure the output keel straight and then there is no twisting or sideways bedding.
- For safety reason, the whole operation is processed by computer, controller or PCL station.
- For non-stop production, this machine is designed with a storage, welding machine. Non-shop shearing device and run out table.
Technical specification of C/U Channel Roll Forming Machine
| Raw material | Item | Parameter | Notice |
| Material thickness | 0.4—0.8mm | Big thickness may cause tolerance | |
| Material type | GI | Special material should be tested. | |
| Material hardness | 550—350 mpa | ||
| Production | Formed width | 28/60mm | |
| Forming speed | Â 20m/min | ||
| Machine Material | Roller | Gr12 | |
| Shaft | Cr40 | ||
| Rolling station | QT470 | ||
| Shearing blade | Cr 12 MOV | ||
| Line speed | Roll forming speed | 20m/min | |
| Transmission | Gear box | ||
| Shearing | Flying Shearing | Adjustable | |
| Product Supporter | Discharging table | 6m/8/12 | Adjustable |
| Hydraulic Station | PLC | motor Power: 3kw | Brand could be customized |
| Accessories | conk 2 pcs, fuse-link 4 pcs, Rubber mat 1 pcs, Bolt spanner 1 pcs |
